Wethepeople Utopia Flatland Frame (2022)
A pure-bred flatland machine, the utopia frame is the most advanced flatland specific frame we’ve ever made. Based around modern flatland geometry, a kinked top tube for extra clearance and all new super-lightweight hydroformed tubing, this is one of the only flatland frames available.
Tubing - butted, japanese seamless 4130 crmo tubing
Bottom bracket - 74mm mid size, cnc machined and heat-treated
Head tube - 110mm cnc machined and heat-treated, integ. H/set
Dropouts - laser cut and cnc machined 6mm, heat-treated 4130 crmo, perfect shape for pegs, integrated chain tensioner
Brakes - brakeless frame
• technical flatland frame, shorter top tube and lower seat tube for younger riders
• hydroformed top and down tube for superior strength and stiffness
• kinked top tube for increased foot clearance
• tapered seat stays and chain stays with bullet tipped ends
• curved seat stay bridge and chain stay bridge
• frame comes with 14mm slot dropouts
• curved seat stay bridge and chain stay bridge
• wider rear triangle allows clearance for a 2.3"" tire
• 6mm seat clamp bolt
• includes lifetime guarantee
Weight - 1.92kg – 20""
Frame geometry
Top tube length - 19"" or 20""
Chain stay length - 12.4"" - 13.2"" - optimized for 12.5""/12.75"" w/25-9
Head tube angle - 75°
Seat tube angle - 71°
BB height - 12.3""
Standover height - 6.2""
