SE have really upped the ante this year with the introduction of the 29” Big Ripper HD. This bad boy comes equipped with Tektro hydraulic disc brakes and a LOUD 9-pawl 16T freewheel. The frame features an internally machined integrated head tube, Floval Tubing, looptail rear end, American bottom bracket, and classic PK Ripper style wishbone plate. Combine all of this with the super grippy SE Bozack tyres and this very well may be the raddest Big Ripper yet.
- Retro 6061 aluminum Big Ripper frame with Floval tubing, internally machined integrated head tube, looptail rear end, American bottom bracket, and classic PK Ripper style wishbone plate
- Full Cr-Mo Landing Gear forks
- FSA Orbit CE integrated sealed bearing headset
- Double-wall rims with sealed-bearing and high-flange hubs and LOUD 9-pawl 16T freewheel
- SE 3-piece V-Ridge cranks with alloy SE sprocket
- Authentic ODI Mushroom II grips with 45 Years of Radness SE Donuts
- SE Bozack 29” x 2.4” tyres
- SE Flyer seat with SE bottle opener
- Tektro hydraulic disc brakes with easy to adjust open system, dual piston, 160mm rotors
- SE 45 Year Anniversary padset
- SE Wheelie pegs
- 15.19 kgs
| Size | 23.6TT |
| Frame | 6061 Aluminum Floval Tubing, Internally-machined Integrated Head Tube, Looptail Rear End, 68mm American Bottom Bracket, Wide Rear Stays, Retro Dropouts TOP TUBE, ACTUAL 23.6"" SEAT TUBE, CENTER TO TOP 16.9"" SEAT TUBE ANGLE 71° HEAD TUBE ANGLE 71° CHAINSTAY LENGTH 18.25"" WHEELBASE 44"" BOTTOM BRACKET HEIGHT 12.25"" STANDOVER 30.75"" SUGGESTED RIDER SIZE 5'5""+ (165cm+) |
| Fork | Landing Gear, Full Cr-Mo, Disc Tabs |
| Headset | FSA Integrated Orbit CE, Sealed 1-1/8"" |
| Stem | Retro Alloy Top-Load w/ Engraved SE Logo on Top & Sides, 55mm Reach |
| Handlebar | Big Honkin' Cr-Mo Cruiser Bar, 29"" x 7"", 12° Backsweep, 2° Upsweep |
| Grips | Special Edition ODI Mushroom II Dual-Ply Grips, Made in USA, w/ 45 Years of Radness SE Donuts |
| Brake | BRAKESET Tektro HD-M285, Hydraulic Disc, Easy to Adjust Open System, Dual Piston, Automatic Caliper Positioning, 160mm Rotors BRAKE LEVERS Tektro HD-M285, 2-Finger Alloy, Front & Rear |
| BB |
|
| Crank | SE V-Ridge 3-pc Cr-Mo Cranks, 175mm, Sealed American Bottom Bracket, 160mm Spindle Length, 19mm Spindle Diameter, 36T Alloy SE Racing Sprocket |
| Sprocket |
|
| Chain | KMC S1 |
| Pedals | Wellgo Low-profile Platform |
| Front Hub | SE Racing Alloy 36H Disc Hubs, 100mm Front Hub |
| Rear Hub | SE Racing Alloy 36H Disc Hubs, 135mm Sealed Rear Hub, 16T 9-Pawl LOUD Freewheel |
| Rims | Double-wall Rims |
| Tyres | SE Bozack, Street Proven Multi Purpose Compound, Wrap Around Urban Tread Pattern, Grooved SE Wing Logo, 29"" x 2.4"" Front & Rear |
| Seat / Post | SEAT SE Flyer Seat w/ Custom SE Bottle Opener Brace SEATPOST Micro-Adjust Alloy, 27.2mm SEAT CLAMP SE Racing Champ Clamp, Alloy, 31.8mm Inner Diameter |
| Weight | 15.19 kgs |
| Extras | 45 Years of SE Radness Padset, Alloy Valve Caps, SE Wheelie Pegs |
