The Rift ES20 Expert XL frame is here in all new colours for the 2023/24 race season. From classic grey charcoal with black decals, to hot pink, with a few colours in between, all of the frames are finished in a gloss clear coat covering the decals and adding an extra layer of protection. We reckon the kids will love these bright colours.
Rift haven't quite gone all the way with disc brake adaptation, with all of the youth frames sticking to a V-brake design, though we're 100% positive there will be disc brake conversions on the track for 2024. With a slotted 10mm dropout, there's plenty of caliper mount options out there.
Manufactured from 7005 Double Heat Treated Alloy, all of the main tubing is hydro-form making for a unique appearance. The CNC'd 3D dropouts are both beautiful and functional, and will for sure be dead straight making wheel installation dead easy.
A Euro bottom bracket means the crank install is also a quick and easy process. No messy silicon and multiple cable guides keeps your build looking sleek.
Rift frames are popular for good reason and the attention to detail on these has us excited to be offering them to you guys through LUX.
Note: The maroon and green frames here are the youth frames and are showing V-brake mounts. The other colours are pro frames and show the disc brake dropouts. These images are simply to display the colour options.
Features:
- 7005 Double Heat Treated Alloy
- Hydro-Form Top Tube
- Hydro-Form Down Tube
- Hydro-Form Chain Stays
- CNC CS Yoke for Max Wheel Clearance
- Bulge Seat Tube
- CNC Integrated Head Tube and BB
- CNC 3D Dropouts
- Decals Under Clear Coat
Specs:
| Model | Rift ES20D Expert XL |
| Frame Material | 7005 Double Heat Treated Alloy |
| Top Tube Length | 20.0 Inch |
| Chainstay Length | 13.4 Inch |
| Bottom Bracket Height | 11.00 Inch |
| Head Angle | 73 Degrees |
| Seat Angle | 72 Degrees |
| Head Tube Type | Integrated 1-1/8th |
| Wheel Type | 451mm (20 x 1-1/8 / 20 x 1-3/8th) |
| Bottom Bracket Type | Euro |
| Seat Tube Diameter | 22.2mm |
| Seat Clamp Diameter | 24.5mm |
| Brake Type | V-brake |
| Dropout type | 10mm Slotted |
| Weight | 1219g |
